Data Display System (Gyro Compass)
The REP-151 is a repeater that simultaneously displays data for two compass headings (including roll, pitch and heading), routing data from one input to another output. The REP-241 is a dot-matrix compass-heading tape repeater that shows true heading from 000 to 360° with one decimal over an NMEA0183 serial connection.
Information
Video
3D View
Prefer to order directly? Contact us:
Model REP-151 / REP-241
Name Gyro Indicator / Gyro Repeater
Serial ports 2 input + 1 output, isolated (RS232 & RS422)
Power supply 24 VDC (18–30 VDC)
Input data protocol NMEA 0183
Shock 30 g in 6 ms (operating)
Vibration 1–13.5 Hz 1 mm; 13.5–100 Hz 0.7 g (IEC60945)
Operating temperature -10 °C to +55 °C
Dimensions 210×100×80 mm
Weight 3 kg
